GoodLay Opto

100pcs 3mm RED Clear Round Top LED Light Emitting Diodes DIY Edgeless

100pcs 3mm RED Clear Round Top LED Light Emitting Diodes DIY Edgeless

Regular price $8.42 AUD
Regular price Sale price $8.42 AUD
Sale Sold out
Shipping calculated at checkout.

Mounting Style: Through-Hole

Nominal Current Rating: 15-20mA

Configuration: Single

Viewing Angle: 25°

Item Diameter: 3 mm

Lens Shape: Round

Lens Surface: Clear

Nominal Voltage: 2.0-2.2V

Forward Current: 20 mA

MPN: Does Not Apply

LED Size: 3mm

Wavelength: 620-625nm

Colour: Red

Brand: GoodLay Opto

Type: Individual Item

Number of Pins: 2

LED Colour: Red

Lens Color: Clear

Number of LEDs: 100

Country/Region of Manufacture: China

Current: up to 20 mA (MAX)

UPC: Does not apply

100pcs 3mm Red LED Clear Round Top Light Emitting Diodes no Edge Condition is Brand New. Sent with Australia Post regular letter no tracking.

All large orders sent with Parcel Post with Tracking.

Parameter:

Working current: 20 (mA) max

Working voltage:

Red: 2.0V-2.2V

Yellow: 1.9V-2.1V

Green: 3.0V-3.2V

Blue: 3.0V-3.2V

White: 3.0V-3.2V

Orange:1.9V-2.1V


Wave length:

Red: 620-625nm

Yellow: 590-592nm

Green: 567-570nm

Blue: 460-465nm

White: 6000-15000k

Orange: 600-610nm
